Thiết bị lưu trữ NAS Synology RS3617RPxs
Giải pháp lưu trữ mạnh mẽ
RS3617RPx cung cấp giải pháp lưu trữ vững chắc với hiệu năng tuyệt vời với hơn 134.688 IOPS đọc ngẫu nhiên và 4.380 MB / s thông lượng đọc tuần tự 1 . DDR4 ECC UDIMM đảm bảo độ chính xác và hiệu suất dữ liệu cho các môi trường quan trọng.
Sẵn sàng cho 10GbE và hơn thế nữa
Khe cắm PCIe 3.0 cho phép tùy chọn kết nối mạng nhanh hơn khi bạn mở rộng cơ sở hạ tầng. Cùng với các cổng Quad Gigabit tích hợp, RS3617RPx cung cấp các tùy chọn kết nối toàn diện để tổng hợp liên kết và cấu hình chuyển đổi dự phòng.
Bảo vệ tài sản kỹ thuật số
Được cung cấp bởi Synology DiskStation Manager (DSM), Synology NAS cung cấp các biện pháp bảo mật tiên tiến để bảo vệ chống mất dữ liệu đột ngột và các lỗ hổng bảo mật tiềm ẩn.
Hoàn thành các giải pháp ảo hóa và iSCSI
Bộ lưu trữ iSCSI của Synology hỗ trợ hầu hết các giải pháp ảo hóa như VMware vSphere, Microsoft Hyper-V, Citrix Xen Server và OpenStack Cinder để nâng cao hiệu quả công việc. Bạn có thể chạy và quản lý nhiều máy ảo trên Windows, Linux hoặc DSM bằng Trình quản lý máy ảo.
Hệ thống tập tin thế hệ tiếp theo để bảo vệ dữ liệu tốt hơn
Hệ thống tệp Btrfs giới thiệu các công nghệ lưu trữ tiên tiến và ảnh chụp nhanh được tối ưu hóa để ngăn ngừa hỏng dữ liệu và giảm chi phí bảo trì. Mặc dù đảm bảo tính toàn vẹn dữ liệu cấp cao, nó cũng cung cấp các công cụ phục hồi và bảo vệ dữ liệu linh hoạt, hiệu quả.
Thư mục chia sẻ linh hoạt / Hệ thống hạn ngạch người dùng cung cấp kiểm soát hạn ngạch toàn diện trên tất cả tài khoản người dùng và thư mục dùng chung
Snapshot Replication cung cấp bảo vệ dữ liệu tiết kiệm dung lượng theo lịch trình và lưu trữ với 1.024 bản sao lưu thư mục dùng chung và 65.000 ảnh chụp nhanh toàn hệ thống
Phục hồi dữ liệu ở cấp độ tệp hoặc thư mục giúp phục hồi dữ liệu nhanh chóng và linh hoạt
Tự động tự phục hồi tệp phát hiện và phục hồi các tệp bị hỏng mà không cần sự can thiệp của người dùng
Thông tin phần cứng
CPU
|
Intel Xeon D-1521 quad-core 2.4GHz burst up to 2.7GHz
|
Hardware encryption engine
|
Yes (AES-NI)
|
Memory
|
8GB DDR4 ECC UDIMM (expandable up to 64GB)
|
Compatible drive type
|
12 x 3.5" or 2.5" SATA (hard drives not included)
|
Maximum internal raw capacity
|
168TB (12 x 14TB HDD)3 (The actual capacity will differ according to volume types)
|
External ports
|
USB 3.0 x 2, Expansion port (Infiniband) x 2
|
Size (HxWxD)
|
88 mm x 430.5 mm x 692 mm
|
Weight
|
14.5 kg
|
LAN
|
1GbE (RJ-45) x 4
|
PCIe 3.0 x8 slot
|
Two running at x8 mode, supports two dual-port 10GbE network interface cards
|
Wake on LAN/WAN
|
Yes
|
Wireless support (dongle)
|
Yes
|
AC input power voltage
|
100V to 240V AC
|
Power frequency
|
50 / 60Hz, single phase
|
Operating temperature
|
5 to 35°C (40 to 95°F)
|
Storage temperature
|
-20 to 60°C (-5 to 140°F)
|
Relative humidity
|
5% to 95% RH
|
Thông tin DSM
Networking protocols
|
SMB, AFP, NFS, FTP, WebDAV, CalDAV, iSCSI, Telnet, SSH, SNMP, VPN (PPTP, OpenVPN™, L2TP)
|
File system
|
Internal: Btrfs, ext4
External: Btrfs, ext4, ext3, FAT, NTFS, HFS+, exFAT4
|
Storage management
|
Maximum single volume size: 108TB/200TB (at least 32GB RAM required, for RAID 5 or RAID 6 groups only); maximum internal volume: 1,024,
maximum iSCSI target: 64, maximum iSCSI LUN: 512, RAID clone/snapshot support; Synology Expansion Unit support: RX1217/RX1217RP
|
Supported RAID type
|
Basic, JBOD, RAID 0, RAID 1, RAID 5, RAID 6, RAID 10
|
File sharing capability
|
Maximum user account: 16,000; maximum group: 512; maximum shared folder: 512; maximum concurrent SMB/AFP/FTP/File Station connections : 2,048
|
Privilege
|
Windows Access Control List (ACL)
|
Virtualization ready
|
VMware vSphere 6, Microsoft Hyper-V, Citrix, OpenStack Cinder
|
Directory service
|
Windows AD integration: Domain Users login via Samba (SMB)/AFP/FTP/File Station, LDAP integration
|
Security
|
FTP over SSL/TLS, IP auto-block, firewall, encrypted network backup over Rsync, HTTPS connection
|
Utilities
|
Synology Web Assistant, Cloud Station Drive, Cloud Station Backup, Cloud Sync Decryption Tool, Evidence Integrity Authenticator,
Photo Station Uploader, Snapshot Manager for VMware, Snapshot Manager for Windows, NFS Plug-in for VMware VAAI
|
Supported clients
|
Windows 7 onwards and Mac OS X® 10.10 onwards
|
Supported browsers
|
Chrome™, Firefox®, Internet Explorer® 9 onwards, Safari® 8 onwards, Safari (iOS® 7 onwards on iPad®), Chrome (Android 4.0 onwards on tablets)
|
Language
|
English, Deutsch, Français, Italiano, Español, Dansk, Norsk, Svensk, Nederlands, Русский, Polski, Magyar,
Português do Brasil, Português Europeu, Türkçe, Český,
|
Các ứng dụng
File Station
|
Virtual drive, remote folder, Windows ACL editor, compress/extract archived files, bandwidth control for specific users or groups, create sharing links, transfer
logs
|
Backup solutions
|
Network backup; local backup; desktop backup; configuration backup; OS X Time Machine; backup data to public cloud; shared folder sync - maximum task
number: 16
|
FTP Server
|
Bandwidth control for TCP connections, custom FTP passive port range, anonymous FTP, FTP SSL/TLS and SFTP protocols, boot over the network with TFTP
and PXE support, transfer logs
|
High Availability Manager
|
Combines two RS3617RPxs into one high-availability cluster
|
Security Advisor
|
Malware detection/removal, user account/password, network, system-related security scan
|
iOS/Android™ applications
|
DS cloud, DS file, DS finder, DS cam, DS note, DS audio, DS get, DS photo, DS video
|
Windows Phone® applications
|
DS file, DS finder, DS audio, DS get, DS photo, DS video
|
Các gói
Antivirus Essential
|
Full system scan, scheduled scan, white list customization, virus definition auto update
|
Cloud Station Server
|
Maximum concurrent file transfers: 2,000, retain historical and deleted file versions
|
Cloud Sync
|
One or two-way synchronization with public cloud storage providers including Amazon Cloud Drive, Amazon S3-compatible storage, Baiduyun, Box,
Dropbox, Google Cloud Storage, Google Drive, hubiC, Megafon Disk, Microsoft OneDrive, OpenStack Swift-compatible storage, WebDAV servers, Yandex Disk
|
DLNA/UPnP® Media Server
|
DLNA certified, PS3®/PS4®/Xbox 360®/Xbox One® support
|
Download Station
|
Supported download protocols: BT/HTTP/FTP/NZB/eMule; Maximum concurrent download task: 80
|
Log Center
|
SSL connection, log rotation: 6 months, 1 year, 2 years, 3 years, email notification
|
MailPlus
|
Intuitive webmail interface for MailPlus Server; customizable mail labels, filters and user interface
|
MailPlus Server
|
Secure, reliable, and private mail server solution with High-availability, load balancing, security and filtering design
(Including free MailPlus licenses for 5 mail accounts. Procurement of additional licenses is required.)
|
Note Station
|
Rich-text note organization with versioning, encryption, sharing, media embedding and attachments
|
Storage Analyzer
|
Volume and quota usage, total size of files, volume usage and trends based on past usage, size of shared folders, largest/most/least frequently modified files
|
Surveillance Station
|
Maximum IP camera: 75 (total of 2,250 FPS at 720p, H.264) (Including two free camera licenses. Procurement of additional licenses is required.)
|
VPN Server
|
Maximum connections: 30; supported VPN protocols: PPTP, OpenVPN™, L2TP
|
Web Station
|
Virtual host (up to 30 websites), PHP/MariaDB®, 3rd-party applications support
|
Other packages
|
Photo Station, Audio Station, iTunes® Server, 3rd-party packages
|
