Thiết bị Switch Aruba Instant On 1930 48G Class4 PoE 4SFP/SFP+ 370W (JL686A)

30.250.000đ
Aruba Instant On 1930 48G Class4 PoE 4SFP/SFP+ 370W Switch (JL686A)
48 RJ-45 autosensing 10/100/1000
Class 4 PoE ports (IEEE 802.3 Type
10BASE-T, IEEE 802.3u Type 100BASETX, IEEE 802.3ab Type 1000BASE-T);
Duplex: 10BASE-T/100BASE-TX: half or
full; 1000BASE-T: full only
4 SFP+ 1/10GbE ports
Khuyến mãi

Gọi Hotline 0977 291 551 - 0332 933 286 - 0393 666 894 để nhận nhiều ưu đãi hấp dẫn !

Mua Ngay
Đặt và nhận hàng qua hình thức ship COD

Thông số kỹ thuật Aruba JL686A:

Aruba Instant On 1930 48G Class4 PoE 4SFP/SFP+ 370W Switch (JL686A)
I/O Ports and Slots - 48 Ports GE RJ-45 PoE+
- 4 SFP+ 1/10GbE ports
Physical characteristics
Dimensions 17.42(w) x 12.7(d) x 1.73(h) in (44.25 x 32.26 x 4.39 cm) (1U height)
Weight 9.97 lb (4.52 kg)
Hardware
CPU ARM Cortex-A9 @ 800 MHz
Memory 512 MB SDRAM
Flash 256 MB flash
Packet buffer 1.5 MB
Performance
Switching capacity 176 Gbps
Throughput capacity 130.95 Mpps
Environment
Operating temperature 32°F to 104°F (0°C to 40°C)
Operating relative humidity 15% to 95% @ 104°F (40°C)
Non-operating temperature ‑40°F to 158°F (‑40°C to 70°C)
Non-operating relative humidity 15% to 95% @ 140°F (60°C)
Max operating altitude Up to 10,000ft (3.048 Km)
Acoustics - Pressure: 40.6
- Power: 63.2 dB
Electrical characteristics
Frequency 50Hz/60Hz
AC voltage 100 - 127 / 200 - 240 VAC
Current 5/2.5 A
Maximum power rating 460.0 W
Idle power 34.5 W
PoE power 370 W Class 4 PoE
Safety UL 60950-1; IEC 60950-1;EN 60950-1; CAN/CSA-C22.2 No. 60950-1; EN 60825-1 UL 62368-1 Ed. 2; IEC 62368-1 Ed. 2; EN 62368-1:2014
Emissions VCCI-CISPR 32, Class A; CNS 13438; ICES-003 Issue 6 Class A; FCC CFR 47 Part 15, Class A; EN 55032: 2015 +AC:2016 / CISPR-32, Class A
Immunity - Generic CISPR 24 / CISPR 35
- EN EN 55024:2010 / EN 55035:2017 ESD IEC 61000-4-2
- Radiated IEC 61000-4-3
- EFT/Burst IEC 61000-4-4
- Surge IEC 61000-4-5
- Conducted IEC 61000-4-6
- Power frequency magnetic field IEC 61000-4-8
- Voltage dips and interruptions IEC 61000-4-11
- Harmonics IEC 61000-3-2, EN 61000-3-2
- Flicker IEC 61000-3-3, EN 61000-3-3
Device Management Aruba Instant On solution; Web browser; SNMP Manager
